Рассмотрим примеры практического применения данной микросхемы Триггер Шмидта. Это очень простая, но эффективная схема. Схема позволяет, подавая на вход аналоговый сигнал, получить чистый прямоугольный сигнал на выходе - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Простой таймер . Практическое применение в статье Простой таймер включения устройства в ~220V. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Схема для получения более точных интервалов . - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Простой ШИМ Практическое применение в статье ШИМ для вентилятора - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Сумеречный выключатель . Схема встроена в Дополнительный термостат к котлу - - - - - -
